10/100 Fast Ethernet Switch User’s Guide
34
RJ-45 Pin Specification
B
7 RJ-45 P
IN
S
PECIFICATION
When connecting the DES-1016/DES-1024 Switch to another switch, a
bridge or a hub, a modified crossover cable is necessary. Please review
these products for matching cable pin assignment.
The following diagram and tables show the standard RJ-45
receptacle/connector and their pin assignments for the switch-to-network
adapter card connection, and the straight/ crossover cable for the Switch-to-
switch/hub/bridge connection.
The standard RJ-45 receptacle/connector
