D-Link DES-1016D - Switch User Manual

11
IDENTIFYING EXTERNAL COMPONENTS
Front Panel
The figure below shows the front panels of the switch.
16-port 10/100Mbps Fast Ethernet Switch

 LED Indicator Panel
Refer to the next chapter for detailed information about each of the switch’s
LED indicators.
 Power (PWR)
This green LED indicator illuminates when the switch is receiving power;
otherwise, it is off.
 Link / Activity
This green LED indicator illuminates when the port is connected to a Fast
Ethernet or Ethernet station; the indicator blinks when transmitting or
receiving data.

D-Link DES-1016D - Switch Specifications

General

Brand	D-Link
Model	DES-1016D - Switch
Category	Network Router
Language	English
