D-Link DES-1016D - Switch User Manual

12
 Twisted-Pair Ports
These ports support automatic MDI/MDIX crossover detection function
providing true ‘plug and play’ connectivity, which eliminates the need for
crossover cables or uplink ports. Any port can be simply plugged to a server,
workstation, or hub using the usual straight-through, twisted-pair cable.
Rear Panel
AC Power Connector

D-Link DES-1016D - Switch Specifications

General

Device Type	Switch
Form Factor	Desktop
Ports	16 x 10/100
Switching Capacity	3.2 Gbps
MAC Address Table Size	8K entries
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3x
Forwarding Rate	1.488 Mpps
Operating Temperature	0 °C to 40 °C
Storage Temperature	-10 °C to 70 °C
Humidity	10% to 90% non-condensing
Features	Flow control, auto-negotiation, auto-uplink (auto MDI/MDI-X)
Dimensions	280 mm x 44 mm
