14
TECHNICAL SPECIFICATIONS
Performance
Transmits
Method:
Store-and-forward
RAM Buffer: 256KBytes (2Mbits) per device
Filtering
Address Table:
8K entries per device
Packet Filtering/
Forwarding
Rate:
10Mbps Ethernet: 14,880/pps
100Mbps Fast Ethernet: 148,809/pps
MAC Address
Learning:
Automatic update

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the D-Link DES-1016D - Switch and is the answer not in the manual?

D-Link DES-1016D - Switch Specifications

General IconGeneral
Device TypeSwitch
Form FactorDesktop
Ports16 x 10/100
Switching Capacity3.2 Gbps
MAC Address Table Size8K entries
Compliant StandardsIEEE 802.3, IEEE 802.3u, IEEE 802.3x
Forwarding Rate1.488 Mpps
Operating Temperature0 °C to 40 °C
Storage Temperature-10 °C to 70 °C
Humidity10% to 90% non-condensing
FeaturesFlow control, auto-negotiation, auto-uplink (auto MDI/MDI-X)
Dimensions280 mm x 44 mm
