D-Link DES-1016D - Switch User Manual

13
TECHNICAL SPECIFICATIONS
General
Standards
IEEE 802.3 10BASE-T Ethernet
IEEE 802.3u 100BASE-TX Fast Ethernet
IEEE 802.1p Compliance
Protocol CSMA/CD
Data Transfer
Rate
Ethernet: 10Mbps (half duplex), 20Mbps (full-duplex)
Fast Ethernet: 100Mbps (half duplex), 200Mbps (full- duplex)
Topology Star
Network Cables
10BASET: 2-pair UTP Cat. 3,4,5, EIA/TIA- 568 100-ohm STP
100BASE-TX: 2-pair UTP Cat. 5, EIA/TIA-568 100-ohm STP
Number of
Ports
16 x 10/100Mbps Auto-MDI/MDIX ports
Physical and Environmental
AC inputs 100 to 240 VAC, 50 or 60 Hz internal universal power supply
Power
Consumption
2.3 Watts.
Temperature
Operating: 0 ~ 40 C (32º to 104º F), Storage: -10 ~ 70 C
(14º to 158º F)
Humidity Operating: 10% ~ 90%, Storage: 5% ~ 90%
Dimensions
Width x Depth x Height
280 x 125.8 x 44 mm
(11.0 x 5.0 x 1.7 inches )
EMI: FCC Class A, ICES-003 Class A, CE Class A, VCCI Class A
Safety cUL, LVD

D-Link DES-1016D - Switch Specifications

General

Device Type	Switch
Form Factor	Desktop
Ports	16 x 10/100
Switching Capacity	3.2 Gbps
MAC Address Table Size	8K entries
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3x
Forwarding Rate	1.488 Mpps
Operating Temperature	0 °C to 40 °C
Storage Temperature	-10 °C to 70 °C
Humidity	10% to 90% non-condensing
Features	Flow control, auto-negotiation, auto-uplink (auto MDI/MDI-X)
Dimensions	280 mm x 44 mm
