D-Link DIR-505 User Manual

155D-Link DIR-505 User Manual
Section 5 - Connecting to a Wireless Network
3. Enter the same security key or passphrase that is on your router and
click Connect.
It may take 20-30 seconds to connect to the wireless network. If the
connection fails, please verify that the security settings are correct. The
key or passphrase must be exactly the same as on the wireless router.

D-Link DIR-505 Specifications

General

Frequency Band	2.4 GHz
USB Port	1 x USB 2.0
Standards	IEEE 802.11n, IEEE 802.11g, IEEE 802.11b, IEEE 802.3, IEEE 802.3u
Wireless Speed	Up to 150 Mbps
Antenna	Internal Antenna
Wireless Standard	802.11b/g/n
Ethernet Ports	1 x 10/100 Mbps
Security	WEP, WPA, WPA2
Operating Modes	Router, Access Point, Wi-Fi Hotspot
Weight	97.7 grams (3.44 ounces)
Power Supply	AC Input: 100 to 240 V AC, 50/60 Hz
