D-Link DIR-505 User Manual

23D-Link DIR-505 User Manual
Section 2 - Installation
4. From your iOS mobile device, click Settings.
5. Click Wi-Fi and select the network (SSID) that you assigned during initial
setup. Then, enter your Wi-Fi password.
6. Once connected click on the SharePort Mobile icon.
7. Then, the following screen will pop up.
Settings
90mm
54mm
Web browser link:
http://dlinkrouter or
http:// 192.168.0.1
Default conguration
Username: “Admin”
Password: ““ (leave the eld blank)
Wi- Fi Name (SSID) :
dlinka8fa
Wi-Fi Password :
akbdj19368
Web browser link:
http://dlinkrouter or
http:// 192.168.0.1
Your conguration
Username: Admin
Password:
Wi- Fi Name (SSID) :
Wi-Fi Password :
D-Link DIR-505 Mobile Companion Wi-Fi Conguration Note

D-Link DIR-505 Specifications

General

Frequency Band	2.4 GHz
USB Port	1 x USB 2.0
Standards	IEEE 802.11n, IEEE 802.11g, IEEE 802.11b, IEEE 802.3, IEEE 802.3u
Wireless Speed	Up to 150 Mbps
Antenna	Internal Antenna
Wireless Standard	802.11b/g/n
Ethernet Ports	1 x 10/100 Mbps
Security	WEP, WPA, WPA2
Operating Modes	Router, Access Point, Wi-Fi Hotspot
Weight	97.7 grams (3.44 ounces)
Power Supply	AC Input: 100 to 240 V AC, 50/60 Hz
