D-Link DIR-600 User Manual

51D-Link DIR-600 User Manual
Section 3 - Conguration
To enable a route, check the box that is on the left side of
the route.
Use the drop-down menu to specify if the IP packet must
use the WAN or LAN interface to transit out of the Router.
Enter the IP address of the packets that will take this route.
Enter the subnet mask to specify the subnet of the IP
packets that will take this route.
Enter the next hop that will be taken if this route is used.
Enable:
Interface:
Destination:
Subnet Mask:
Gateway:
Routing
The Routing option is an advanced method of customizing specic routes of data through your network.
Click the Save Settings button to save any changes made.

D-Link DIR-600 Specifications

Wireless Signal Rates

IEEE 802.11n 20MHz Channel	65/72.2 Mbps (max)
IEEE 802.11n 40MHz Channel	135/150 Mbps (max)
IEEE 802.11g	54 Mbps - 48 Mbps - 36 Mbps - 24 Mbps - 18 Mbps - 12 Mbps - 11 Mbps - 9 Mbps - 6 Mbps

Operating Environment

operating temperature	0 °C to 40 °C (32 °F to 104 °F)
storage temperature	-20 °C to 65 °C (-4 °F to 149 °F)
humidity range	10% to 95% (non-condensing)

Frequency Range

wireless frequency range	2.4 GHz to 2.4835 GHz (802.11g/n)

Weight and Dimensions

length	160 mm (6.3 inches)
width	120 mm (4.72 inches)
height	59 mm (2.32 inches)
