D-Link DSL-2740B User Manual

96
Physical and Environmental
DC Inputs:
Power Adapter:
Input: 120V AC 60Hz
Output: 12V AC, 1200mA
Power
Consumption:
12 Watts (max)
Operating
Temperature:
0° to 40°C
Storage
Temperature
-20° to 70°C
Humidity:
5% to 95% (non-condensing)
Dimensions:
109 mm x 142.8 mm x 32.1 mm
Weight:
200 gm
EMI:
CE Class B, FCC Class B (Part 15)
Safety:
CSA 950, UL 1950, IEC 60950, EN 60950
Reliability:
Mean Time Between Failure (MTBF) min. 4 years

D-Link DSL-2740B Specifications

ADSL Standards

downstream data rate	up to 8 Mbps
upstream data rate	up to 1 Mbps
G.lite downstream data rate	up to 1.5 Mbps
G.lite upstream data rate	up to 512 Kbps
G.dmt.bis downstream data rate	up to 12 Mbps
G.dmt.bis upstream data rate	up to 12 Mbps

ADSL2 Standards

full rate downstream data rate	up to 24 Mbps
full rate upstream data rate	up to 1 Mbps

Wireless LAN

wireless speed	up to 300 Mbps
frequency range	2.4 GHz to 2.484 GHz
antennas	2 non-detachable dipole
