D-Link DWA-182 User Manual

51D-Link DWA-182 User Manual
Appendix B - Networking Basics
Windows® 7 Users
t $MJDLPOStart > Control PanelNBLFTVSFZPVBSFJO$MBTTJD7JFX%PVCMFDMJDLPOUIFNetwork and Sharing Center icon. If you are using
8JOEPXT7JTUBDMJDLPOManage network connections BMPOHUIFMFGUQBOFMJOUIFXJOEPX'PS8JOEPXT¥DMJDLPOChange adapter
settings.
t 3JHIUDMJDLPOUIFLocal Area Connection which represents your D-Link wireless network adapter which will be connected to your network.
t )JHIMJHIUInternet Protocol Version 4 (TCP /IPv4) and click Properties.
t $MJDLUse the following IP address and enter an IP address that is on the same
subnet as your network or LAN IP address on your router or network.
Example:*GUIFSPVUFST-"/*1BEESFTTJTNBLFZPVS*1BEESFTT
192.168.0.X where X is a number between 2 and 99. Make sure that the number
you choose is not in use on the network.
t 4FUDefault Gateway the same as the LAN IP address of your router or gateway.
t 4FUPrimary DNS the same as the LAN IP address of your router or gateway.
t 5IFSecondary DNS is optional (you may enter a DNS server from your ISP).
t $MJDLOK to save your settings.

D-Link DWA-182 Specifications

Power

current consumption (Tx)	495 mA
current consumption (Rx)	220 mA
operating voltage	5.0 VDC +/- 10%

Operating Environment

operating temperature	32°F to 104°F (0°C to 40°C)
operating humidity	10% to 90% maximum (non-condensing)

Weight and Dimensions

dimensions	3.8 x 1.1 x 0.5 inches (97.3 x 29.1 x 13.5 mm)
weight	21.94 grams
