4D-Link R12 User Manual
Section 1 - Product Overview
Hardware Overview
LED Indicators
1
Power
Solid White The device is on and the system is healthy.
Solid Orange The device is booting up or performing factory reset.
Blinking Orange &
White Alternately
The device is undergoing the rmware upgrade process.
2 Internet
Solid White The Internet connection is established.
Orange
The device cannot connect to the Internet.
The device is performing rmware upgrade if the above Power LED is
ashing at the same time.
3
Wireless
(2.4 GHz)
Solid White The 2.4 GHz wireless band is enabled.
Blinking White
The device is transmitting data. It is processing WPS if the below 5 GHz
LED is blinking at the same time.
4
Wireless
(5 GHz)
Solid White The 5 GHz wireless band is enabled.
Blinking White
The device is transmitting data. It is processing WPS if the above 2.4 GHz
LED is blinking at the same time.
1 2 3 4
