Daewoo DSB-F183L User Manual

2
Indoor Cover
Electric Dust Collector
(Air clean Plasma)
Removes small dust and
generates (-) ions.
Deodorizing Filter
Removes bad
smells from the air.
Emergency/Remote Switch
Indicators
Indicate the
AC setting.
Remote
Sensor
Power Plug
Sensor Wire
LCD Remote
Controller
Air Cleaning Filters
Removes dust and
prohibits germs.
AIR OUT
AIR IN
Fan Direction
(Up/Down)
Fan Direction
(Left/Right)
M
O
D
E
S
L
E
E
P
O
N
/
O
F
F
T
I
M
E
R
E
N
T
E
R
/
C
A
N
C
E
L
F
A
N
S
P
E
E
D
T
U
R
B
O
/
M
I
L
D
F
A
N
D
I
R
.
LOCATION OF CONTROLS
OPERATING SECTION
INDOOR UNIT
OUTDOOR UNIT
Connection Cover
Remove cover to access the AC connection
from this unit to the indoor unit.
Service Valves
The indoor and outdoor units
are connected by copper tubes
which are connected here.
AIR IN
AIR OUT
