1. SPECIFICATIONS
2
2.FEATURE AND TECHNICAL EXPLANATION
NO. ITEM SPECIFICATIONS
1 POWER SOURCE AVAILABLE IN ALL LOCAL AC VOLTAGE AND CYCLE
2 POWER CONSUMPTION INPUT : 400W, OUTPUT : 210W
3 MACHINE WEIGHT 50 kg. (GROSS WEIGHT : 53kg.)
4 DIMENSION (WXHXD) 612 X 945 X 622 mm
5 WASHING COURSE FULL AUTOMATIC 8 OF COURSES (SOAK, SPEED, BLANKET,
FUZZY, DRY, SILK, STRONG, NIGHT)
6 WATER CONSUMPTION NORMAL 207L
7 WATER LEVEL SELECTOR HIGH (80L), MID (68L), LOW (55L), E.LOW (42L)
8 OPERATING WATER PRESSURE 0.3kg/cm
2
~ 8kg/cm
2
(2.94 N/cm
2
~78.4N/cm
2
)
9 REVOLUTION PER MINUTE SPIN : 680 R.P.M., WASH : 130 R.P.M.
10 PULSATOR 6 WINGS (Ø 376 mm)
11 WATER LEVEL CONTROL ELECTRONICAL SENSOR
12 OUTER CABINET PCM (Pre-Coated Metal) SHEET
13 ANTI-NOISE PLATE O
14 GEAR MECHANISM ASS’Y HELICAL GEAR FOR LOW NOISE
15 LINT FILTER O
16 SOFTENER INLET O
17 FUNCTION FOR SOAK WASH O
18 ALARM SIGNAL O
19 RESIDUAL TIME DISPLAY O
20 AUTO WATER SUPPLY O
21 NEW WATER FLOW WATER FLOW FOR ADJUST THE UNBALANCED LOAD
22 TRANSPARENT WINDOW O
23 FUNCTION FOR BUBBLE O
FEATURE OF THE WASHING MACHINE
1) The first air bubble washing system in the world.
2) Quiet washing through the innovational low-noise design.
3) The wash effectiveness is much more enhanced because of the air bubble washing system.
4) The laundry detergent dissolves well in water because of the air bubble washing system.
5) The adoption of the water surrents to adjust the unbalanced load.
6) One-touch operation system.
WATER CURRENT TO ADJUST THE UNBALANCED LOAD
It is a function to preventy eccentricity of the clothes after wash by rotating pulsator C.W and C.C.W for 20
seconds.(But, the DRY & SILK course have no operation of the water currents to adjust the unbalnced
load.)
EFFECT
It reduces vibration and noise effectively while spinning.
WATER FLOW
FUNCTION FOR SOAK WASH
DISPLAY THE RESIDUAL TIME
When the SOAK WASH is selected, the total wash time increases because 60 minutes for soak process
are added to the time of main process.
PROGRESS
AUTOMATIC WATER SUPPLY SYSTEM FOR BLANKET WASH
The water level would be lowered because the blanket absorbs water at the beginning of washing.
Therefore, after 30 seconds, the operation is interrupted to check the water level, and then the water is
supplied again until the selected water level is reached.
WASH DRAIN SPIN FILL RINSE 1 DRAIN SPIN FILL RINSE 2 DRAIN •••
MOTOR C.W
TOTAL
SINGAL C.C.W
ETC. COURSE(SEC.) 0.3 0.5 0.3 0.5 0.3 0.5 20 SEC.
FUZZY H. 0.6 0.4 0.6 0.4 0.6 0.4 30 SEC.
COURSE M. 0.6 0.4 0.6 0.4 0.6 0.4 30 SEC.
L. 0.5 0.4 0.5 0.4 0.5 0.4 25 SEC.
S 0.3 0.5 0.3 0.5 0.3 0.5 20 SEC.
FILL WASH STOP WASH STOP WASH STOP
• 1’ 19’ 1’ 19’ 1’ 19’
SOAK PROCESS MAIN PROCESS
60 Minutes
