63 64
NO. PARTS CODE PARTS NAME DESCRIPTION Q’TY REMARK
C01 3614508300 PLATE UPPER PP 1
C02 7122401265 SCREW TAPPING T2S TRS 4X12 BSNI 6
C03 3611402800 COVER BACK PP 1
C04 7112401011 SCREW TAPPING T1 TRS 4X10 MFZN 4
C05 3614509600 PLATE LOWER PP 1
C06 7122401265 SCREW TAPPING T2S TRS 4X12 BSNI 4
C07 7001401065 SCREW MACHINE PAN 4X10 BSNI 1
C08 4509K64000 HARNESS OUTER
50/0.18GREEN, ST710095-2
1
C09 3612600700 HANDEL CANINET PR-HD 2
C10 7122401613 SCREW TAPPING T2S TRS 4X16 MFCR 1
C11 36100B2100 ASSY CONDENSER 400VAC(13.5µ+60µH) 1 NE
3610045630 400VAC(11.4µ+60µH) 1 NE
36100B2100 400VAC(15.0µ+60µH) 1 LE
3610076130 200VAC(54.0µ+60µH) 1 TE
3610076230 200VAC(41.6µ+60µH) 1 SE
C12 3611301200 CORD POWER AS 3X1.25SQ X 2.3 1 NE/ME/LE
3611301800 3X2.0SQX2.3 1 TE/SE
C13 4505A63030 C.E.C. SMALL ST CE-230 2
C14 3618905100 UNIT FUSE FILTER 471D-14A 1 NE/ME/LE
3618905110 471D-14A 1 TE/SE
C15 5FKGD1032S FUSE GLASS TUBE AC 250V/10A 1 NE/ME/LE
5FKGD1832S AC 250V/18A 1 TE/SE
C16 4509L03031 COVER DRAIN HOLE PE-HD 1
C17 3617700400 LEG FIX RUBBER BUTYL 2
C18 4509M10032 FIXTURE PP 2
C19 7122502011 SCREW TAPPING T2S TRS 5X20 MFZN 2
C20 7112401411 SCREW TAPPING T1 TRS 4X14 MFZN 13
C21 7122401211 SCREW TAPPING T2S TRS 4X12 MFZN 6
C22 3610904100 CAP LEG ABS, AL COATING 2
C23 3618900700 UNIT LEG RUBBER+BOLT 2
C24 3612000200 FIXTURE LEG PPG 2
C25 3613000600 HOLDER LEG ABS 2
C26 3610303600 BASE U PP 1
C27 3610800700 CABINET PCM 0.7T 1
C28 3611604820 DECORATOR AS
AL COATING LABEL
1
3613501800 LABEL POWER UV COATING 1 OPTION
C29 3612200200 FRAME T PP 1
C30 7112401411 SCREW TAPPING T1 TRS 4X14 MFZN 19
T01 3610085500 ASSY FILTER PP (NYLON 74X130) 1
PARTS LIST (DWF-1095xE MODEL)
NO. PARTS CODE PARTS NAME DESCRIPTION Q’TY REMARK
H08 3612004600 FIXTURE PPS 2
H09 3612800200 HEATER AC 220~240V 1
NE/ME/LE/PN/PM/PL
3612800210 AC 100~130V 1
TE/SE/PT/PS/PA
H10 3612300800 GASKET(C) POLY-URETHANE 1
H11 3611407400 COVER PET 1
H12 7122401611 SCREW TAPPING T2S TRS 4X16 MFZN 6
H13 3612300700 GASKET (B) POLY-UPETHANE 1
H14 3612718801 HARNESS SUB DWF-1095 1
NE/ME/LE/PN/PM/PL
3612718810 DWF-1095 1
TE/SE/PT/PS/PA
H15 5FKGD1222L FUSE GLASS TUBE KS TL 1.25A 250V MF51 1
NE/ME/LE/PN/PM/PL
5FKGB2522L KS TL 2.5A 250V MF51 1
TE/SE/PT/PS/PA
H16 3618905410 UNIT FUSE AS AC 250V/15A, 150°C 1
To Next Page
