DIRECTIONS FOR DISASSEMBLY AND ADJUSTMENT
14
DRAIN MOTOR AND VALVE REPLACEMENT (NON PUMP MODEL)
1 Lay the top of the washer on the floor.
2 Loosen two special screw of drain motor.
5 Turn the valve by using screw driver as shown in
picture.
3 Take out the wire of drain motor from the bracket.
4 Separate the drain motor from the base.
6 Remove the valve lid from the valve drain ass’y.
To Next Page
