THE REPAIR METHOD
19
No. Process Notice
Assemble 1
1
2
3
4
Assemble the coupling
Assemble the new clutch boss
ass’y
Assemble the pulley
Assemble the spring washer
Check the uneven face of
coupling is assembled upward.
- Push in the clutch boss ass’y
with rotating on the clockwise
direction.
-
After assembling, rotate on
the clockwise more 2~3 teeth
and pull out the pulley shaft
upward.
If there was plain washer, you
have to assemble plain washer
the first and then assemble
spring washer.
THE PROCESS OF ASSEMBLE
