2. STRUCTURE OF THE WASHING MACHINE
STRUCTURE
3
Accessories
The parts and features of your washer are illustrated on this page.
Become familiar with all parts and features before using your washer.
NOTE
• The drawing in this book may vary from your washer model. They are designed to show the different
features of all models covered by this book. Your model may not include all features.
• HOT WATER TAP
After using the washer, close the water tap.
In case of the single valve model, there is
no hot water valve.
• COLD WATER TAP
After using the washer,
close the water tap.
• BLEACH INLET
• SOFTENER INLET
• DETERGENT CASE
• GROUND WIRE
In case of 3-wire power cord,
ground wire will not be provided.
• POWER CORD
• LINT FILTER
• CONTROL PANEL
• POWER SWITCH
• PULSATOR
• ADJUSTABLE LEG
COVER UNDER [OPTION] WATER TAP ADAPTER INLET HOSE
HOSE DRAIN [FOR PUMP]
HOSE DRAIN CLAMP HOSE DRAIN[FOR NONPUMP] CONNECTOR INLET [OPTION]
3613218800 3613226600
