DIRECTIONS FOR INSTALLATION AND USE
5
FOR ORDINARY TAP
6
Connect the inlet hose adapter
of the hose to the water inlet of
the washer by turning it
clockwise to be fixed tightly.
• Please check the rubber packing
inside the inlet hose adapter of
the hose.
1
Pull down the collar
of the inlet hose to
separate it from the
water tap adapter.
2
Loosen the four
screws at the water
tap adapter, but don’t
loosen the screws until
they are separated from
the water tap adapter.
4
Remove the tape,
and screw connector
B into connector A tightly.
5
Connect the inlet
hose to the water tap
adapter by puling down
the collar of the hose end.
3
Connect the water tap
adapter to the water tap
tighten the four screws evenly
while pushing up the adapter
so that the rubber packing
can stick to the water tap
tightly.
■
HOW TO CONNECT THE INLET HOSE
Be careful not to mistake in supplying between the hot(maximum : 50˚C) and cold water.
In using only one water tap or in case of attached one water inlet valve, connect the inlet hose to the cold water inlet
valve.
Do not over tighten : This could cause damage to couplings.
FOR SCREW-SHAPED TAP
3
Insert the inlet hose adapter
into the water inlet of a washer
and turn it to be fixed.
• Assert the packing in the inlet.
1
Connect the inlet
hose to the water tap
by screwing the
connector D tightly.
2
Connect the
connector-inlet
supplied if necessary.
To Next Page
