Daewoo DWF-4220 Series User Manual

14
HOW TO CONNECT THE INLET HOSE
In Installing the Inlet Hose
¶
Connect the inlet
hose to the water tap
by screwing the
connector D tightly.
Connector D
Connector C
Rubber
Packing
Hose
™
Connect the connector C of the inlet hose to the
water inlet of the
washer by turning
it clockwise to be
fixed tightly.
• Please check the
rubber packing
inside the connector
C of the inlet hose.
Water Tap
Adapter
Rubber
packing
Connector C
Collar
™
Loosen the four
screw at the water
tap adapter, but
don't loosen the
screws until they are
separated from the
water tap adapter.
Connector A
Tape
Connector B
Tap
Adapter
@
!
Connector B
∞
Connect the inlet
hose to the water tap
adapter by pulling
down the collar of
the hose end.
§
Connect the con-
nector C of the inlet
hose to the water inlet
of the washer by
turning it clock-wise
to be fixed tightly.
• Please check the rubber
packing inside the
connector C of the inlet
hose.
For Screw-Shaped Tap
¡
Pull down the collar
of the inlet hose to
separate it from the
water tap adapter.
£
Connect the water
tap adapter to the
water tap, and tighten
the four screws
evenly while pushing
up the adapter so that
the rubber packing
can stick to the water
tap tightly.
¢
Remove the tape,
and screw connector
B into connector A
tightly.
