Daewoo DWF-4220 Series User Manual

49
P.C.B PARTS LIST
REF No. PART CODE PART NAME DESCRIPTION REMARK
R18 RD-4Z392JK R CARBON FILM 1/4 3.9kΩ J
R26 RD-4Z392JK R CARBON FILM 1/4 3.9kΩ J
R50 RD-4Z392JK R CARBON FILM 1/4 3.9kΩ J
R52 RD-4Z392JK R CARBON FILM 1/4 3.9kΩ J
R54 RD-4Z392JK R CARBON FILM 1/4 3.9kΩ J
R55 RD-4Z392JK R CARBON FILM 1/4 3.9kΩ J
R63 RD-4Z392JK R CARBON FILM 1/4 3.9kΩ J
R67 RD-4Z392JK R CARBON FILM 1/4 3.9kΩ J
R69 RD-4Z392JK R CARBON FILM 1/4 3.9kΩ J
R70 RD-4Z392JK R CARBON FILM 1/4 3.9kΩ J
R71 RD-4Z392JK R CARBON FILM 1/4 3.9kΩ J
R72 RD-4Z392JK R CARBON FILM 1/4 3.9kΩ J
R73 RD-4Z392JK R CARBON FILM 1/4 3.9kΩ J
R74 RD-4Z392JK R CARBON FILM 1/4 3.9kΩ J
R75 RD-4Z392JK R CARBON FILM 1/4 3.9kΩ J
R9 RD-4Z221JK R CARBON FILM 1/4 220Ω J
R24 RD-4Z221JK R CARBON FILM 1/4 220Ω J
R25 RD-4Z221JK R CARBON FILM 1/4 220Ω J
R30 RD-4Z221JK R CARBON FILM 1/4 220Ω J
R31 RD-4Z221JK R CARBON FILM 1/4 220Ω J
R32 RD-4Z221JK R CARBON FILM 1/4 220Ω J
R33 RD-4Z221JK R CARBON FILM 1/4 220Ω J
R34 RD-4Z221JK R CARBON FILM 1/4 220Ω J
R35 RD-4Z221JK R CARBON FILM 1/4 220Ω J
R36 RD-4Z221JK R CARBON FILM 1/4 220Ω J
R37 RD-4Z221JK R CARBON FILM 1/4 220Ω J
R43 RD-4Z221JK R CARBON FILM 1/4 220Ω J
R44 RD-4Z221JK R CARBON FILM 1/4 220Ω J
R45 RD-4Z221JK R CARBON FILM 1/4 220Ω J
R46 RD-4Z221JK R CARBON FILM 1/4 220Ω J
R47 RD-4Z221JK R CARBON FILM 1/4 220Ω J
R48 RD-4Z221JK R CARBON FILM 1/4 220Ω J
R57 RD-4Z221JK R CARBON FILM 1/4 220Ω J
R58 RD-4Z221JK R CARBON FILM 1/4 220Ω J
R64 RD-4Z221JK R CARBON FILM 1/4 220Ω J
R66 RD-4Z221JK R CARBON FILM 1/4 220Ω J
R13 RD-4Z331JK R CARBON FILM 1/4 330Ω J
