Daewoo DWF-4220 Series User Manual

8
GEAR MECHANISM ASS'Y
The proper water currents is made by the rotation of pulsator at a low speed to prevent the damage to the small sized
clothes.
PRINCIPLE OF BUBBLE GENERATOR
STRUCTURE
Pulsator shaft
One clutch bearing
Brake lever
Spinner shaft
Planetary gear
Clutch spring
Clutch boss
Spinner pulley
Sun gear
Internal gear
Planetary gear
Pulsator
Planetary
V.belt
Spinner
pulley
1 revolution
5 revolutions
Motor
Motor
V.BELT
Planetary
gear
1/5.0
Directly
Spinner Pulley
Pulsator
Tub
Bobbin & coil
Trans core
Magnet
Armature
Bellows
Air out hole
Protector A
Protector B
Air in hole
Air
Air
