Daikin 2MXL18QMVJU Service Manual

SiUS121632EA Indoor Unit
Specifications 15
1.5 FFQ Series
60 Hz, 208 - 230 V
Model
FFQ09Q2VJU FFQ12Q2VJU
Cooling Heating Cooling Heating
Rated Capacity 9 kBtu/h Class 12 kBtu/h Class
Decoration Panel
(1)
Model BYFQ60B3W1 BYFQ60B3W1
Color White White
Dimensions
(H × W × D)
in. (mm) 2-3/16 × 27-9/16 × 27-9/16 (55 × 700 × 700) 2-3/16 × 27-9/16 × 27-9/16 (55 × 700 × 700)
Weight (Mass) Lbs (kg) 6 (2.7) 6 (2.7)
Decoration Panel
(2)
Model BYFQ60C2W1W / BYFQ60C2W1S BYFQ60C2W1W / BYFQ60C2W1S
Color White / Silver White / Silver
Dimensions
(H × W × D)
in. (mm) 1-13/16 × 24-7/16 × 24-7/16 (46 × 620 × 620) 1-13/16 × 24-7/16 × 24-7/16 (46 × 620 × 620)
Weight (Mass) Lbs (kg) 6.2 (2.8) 6.2 (2.8)
Airflow Rate
H
cfm
(m³/min)
378 (10.7) 399 (11.3) 406 (11.5) 427 (12.1)
M 339 (9.6) 357 (10.1) 353 (10.0) 371 (10.5)
L 268 (7.6) 282 (8.0) 268 (7.6) 282 (8.0)
Fan
Type Turbo Fan Turbo Fan
Motor Output W — —
Speed Steps 3 Steps 3 Steps
Air Direction Control — —
Running Current (Rated) A 0.23 - 0.21 0.23 - 0.21 0.27 - 0.24 0.27 - 0.24
Power Consumption (Rated) W 23 23 27 27
Power Factor % 48.1 - 47.6 48.1 - 47.6 48.1 - 48.9 48-1 - 48.9
Temperature Control Microcomputer Control Microcomputer Control
Dimensions (H × W × D) in. (mm) 10-1/4 × 22-5/8 × 22-5/8 (260 × 575 × 575) 10-1/4 × 22-5/8 × 22-5/8 (260 × 575 × 575)
Packaged Dimensions (H × W × D) in. (mm) 11 × 27 × 23-1/2 (280 × 686 × 597) 11 × 27 × 23-1/2 (280 × 686 × 597)
Weight (Mass) Lbs (kg) 36 (16) 36 (16)
Gross Weight (Gross Mass) Lbs (kg) 40 (18) 40 (18)
Sound Pressure
Level
H / M / L dB(A) 38 / 35 / 29 38 / 35 / 29 39 / 36 / 30 39 / 36 / 30
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Piping
Connections
Liquid in. (mm) φ
1/4
(φ
6.4
) φ
1/4
(φ
6.4
)
Gas in. (mm) φ
3/8
(φ 9.5) φ
3/8
(φ 9.5)
Drain in. (mm) VP20 (O.D. φ
1-1/32
(φ 26)) VP20 (O.D. φ
1-1/32
(φ 26))
Drawing No. 3D106061A 3D106062
Model
FFQ15Q2VJU FFQ18Q2VJU
Cooling Heating Cooling Heating
Rated Capacity 15 kBtu/h Class 18 kBtu/h Class
Decoration Panel
(1)
Model BYFQ60B3W1 BYFQ60B3W1
Color White White
Dimensions
(H × W × D)
in. (mm) 2-3/16 × 27-9/16 × 27-9/16 (55 × 700 × 700) 2-3/16 × 27-9/16 × 27-9/16 (55 × 700 × 700)
Weight (Mass) Lbs (kg) 6 (2.7) 6 (2.7)
Decoration Panel
(2)
Model BYFQ60C2W1W / BYFQ60C2W1S BYFQ60C2W1W / BYFQ60C2W1S
Color White / Silver White / Silver
Dimensions
(H × W × D)
in. (mm) 1-13/16 × 24-7/16 × 24-7/16 (46 × 620 × 620) 1-13/16 × 24-7/16 × 24-7/16 (46 × 620 × 620)
Weight (Mass) Lbs (kg) 6.2 (2.8) 6.2 (2.8)
Airflow Rate
H
cfm
(m³/min)
420 (11.9) 441 (12.5) 448 (12.7) 498 (14.1)
M 367 (10.4) 385 (10.9) 378 (10.7) 420 (11.9)
L 293 (8.3) 307 (8.7) 275 (7.8) 307 (8.7)
Fan
Type Turbo Fan Turbo Fan
Motor Output W — —
Speed Steps 3 Steps 3 Steps
Air Direction Control — —
Running Current (Rated) A 0.29 - 0.26 0.29 - 0.26 0.52 - 0.47 0.52 - 0.47
Power Consumption (Rated) W 28 28 51 - 51 51 - 51
Power Factor % 46.4 - 46.8 46.4 - 46.8 47.2 - 47.2 47.2 - 47.2
Temperature Control Microcomputer Control Microcomputer Control
Dimensions (H × W × D) in. (mm) 10-1/4 × 22-5/8 × 22-5/8 (260 × 575 × 575) 10-1/4 × 22-5/8 × 22-5/8 (260 × 575 × 575)
Packaged Dimensions (H × W × D) in. (mm) 11 × 27 × 23-1/2 (280 × 686 × 597) 11 × 27 × 23-1/2 (280 × 686 × 597)
Weight (Mass) Lbs (kg) 36 (16) 39.0 (17.5)
Gross Weight (Gross Mass) Lbs (kg) 40 (18) 42.0 (19.0)
Sound Pressure
Level
H / M / L dB(A) 40 / 37 / 31 40 / 37 / 31 44 / 40 / 32 44 / 40 / 32
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Piping
Connections
Liquid in. (mm) φ
1/4
(φ
6.4
) φ 1/4 (φ 6.4)
Gas in. (mm) φ
1/2
(φ 12.7) φ 1/2 (φ 12.7)
Drain in. (mm) VP20 (O.D. φ
1-1/32
(φ 26)) VP20 (O.D. φ 1-1/32 (φ 26))
Drawing No. 3D106063A 3D106064
Conversion Formulae
kcal/h = kW × 860
Btu/h = kW × 3412
cfm = m³/min × 35.3
