Daikin BRC1E71 User Manual

28 English
Menu Options
Auto mode
Using information from the air conditioner (cool, heat, fan, and
setpoint) and the energy recovery ventilator unit (indoor and
outdoor temperatures), the ventilation mode is automatically
changed between ERV and Bypass.
ERV mode
Outside air is passed through the ERV core and is supplied to the
conditioned space.
Bypass mode
Outside air is supplied to the conditioned space without passing
through the ERV core.
Schedule
Setting the schedule 
Operation
The schedule can not be enabled when a multizone controller is connected.
1
Setting
Main Menu
Air Flow Direction
Ventilation
Schedule
Off Timer
Celsius / Fahrenheit
Maintenance Information
1/2
Display the main menu screen. ●
(See page 22.)
Press ● buttons to select Schedule .
Press Menu/OK button to display the
schedule screen.
Setting
Clock has not been set.
Would you like to set it now?
Schedule
Yes No
Setting
Date & Time
Year 2008
Month 01
Day 01
Tuesday
12
:
00A
Before setting the schedule , the clock ●
must be set.
If the clock has not been set, a screen ●
like the one on the left will appear.
Press buttons to select Yes and
press Menu/OK button.
The date & time screen will appear. ●
Set the current year, month, day, and ●
time. (See clock settings on page 39.)
2
Setting
Schedule
Enable/Disable
Daily Patterns
Settings
Press ● buttons to select the desired
function on the schedule screen and
press Menu/OK button.
01_EN_3P243520-2C.indd 2801_EN_3P243520-2C.indd 28 8/27/2009 1:48:51 PM8/27/2009 1:48:51 PM
