Compressor and Condenser Motor
Table 9: Compressor and Condenser Motor Data – 208/230
Volt
Data
Electrical Data (208/230 V)*
MPS 015B MPS 020B MPS 025B
Compressor Motor
Number 2
Phase 3
RPM 3450
HP, Compressor 1 7-1/2 10 11-1/2
Amps (RLA), Comp. 1 25 33.3 48.1
Amps (LRA), Comp. 1 164 239 245
HP, Compressor 2 7-1/2 7-1/2 11-1/2
Amps (RLA), Comp. 2 25 33.3 48.1
Amps (LRA), Comp. 2 164 239 245
Condenser Motor
Number 4 6
Phase 1
HP 1/3
Amps (FLA, each) 1.2
Amps (LRA, each) 4.7
NOTE: *Unit operating voltage range is 187 – 253
Table 10: Compressor and Condenser Motor Data – 460 Volt
Data
Electrical Data (460 V)*
MPS 015B MPS 020B MPS 025B
Compressor Motor
Number 2
Phase 3
RPM 3450
HP, Compressor 1 7-1/2 10 11-1/2
Amps (RLA), Comp. 1 12.2 17.9 18.6
Amps (LRA), Comp. 1 100 125 125
HP, Compressor 2 7-1/2 7-1/2 11-1/2
Amps (RLA), Comp. 2 12.2 14.7 18.6
Amps (LRA), Comp. 2 100 95 125
Condenser Motor
Number 4 6
Phase 1
HP 1/3
Amps (FLA, each) 0.7
Amps (LRA, each) 2.4
NOTE: *Unit operating voltage range is 414 - 506
Table 11: Compressor and Condenser Motor Data – 575 Volt
Data
Electrical Data (575 V)*
MPS 015B MPS 020B MPS 025B
Compressor Motor
Number 2
Phase 3
RPM 3450
HP, Compressor 1 7-1/2 10 11-1/2
Amps (RLA), Comp. 1 9.0 12.8 14.7
Amps (LRA), Comp. 1 78 80 100
HP, Compressor 2 7-1/2 7-1/2 11-1/2
Amps (RLA), Comp. 2 9.0 12.2 14.7
Amps (LRA), Comp. 2 78 80 100
Condenser Motor
Number 4 6
Phase 1
HP 1/3
Amps (FLA, each) 0.5
Amps (LRA, each) 1.5
NOTE: *Unit operating voltage range is 518 - 632
MCA and MCOP
Table 12: Unit MCA and MCOP Data
MPS Model
Voltage
208/230 460 575
Low Static Fan Drive High Static Fan Drive Low Static Fan Drive High Static Fan Drive Low Static Fan Drive High Static Fan Drive
015
MCA 78.0 81.0 38.0 40.0 28.0 30.0
MCOP 100.0 100.0 45.0 50.0 35.0 35.0
020
MCA 101.0 109.0 52.0 56.0 40.0 42.0
MCOP 125.0 125.0 60.0 70.0 50.0 50.0
025
MCA 147.0 149.0 60.0 63.0 47.0 50.0
MCOP 175.0 175.0 70.0 80.0 60.0 60.0
