Specifications
3-1
Section 3: Specifications
The table on the following pages shows all of the mechanical specifications, circuit specifications and maximum power requirements for each
model in this manual. Models are listed in alphanumeric order.
Notes: Driver address settings can be configured using the J19 address plug or by using the new S1 dip switch found on all GEN IV
drivers. See Section 8.4 for more details.
Signal wires must be a minimum of 22 AWG with shield. Daktronics recommends using W-1614.
Models with an –11 or –12 suffix feature red digits and indicators; suffixes –21 and –22 indicate amber digits.
Model Number of
Sections
Dimensions
(Height, Width,
Depth)
Weight
Uncrated
(Crated)
Digit Size
Digit Color
Maximum
Wattage
Power Amps
per Line
(Single
Phase)
Driver
Number
and
Address
BA-1518 2 Total
Top
Bottom
H8’-0”, W16’-0”, D6”
(2438 mm, 4877
mm, 152 mm)
H3’-0”, W16’-0”, D6”
(914 mm, 4877 mm,
152 mm)
H5’-0”, W16’-0”, D6”
(1524 mm, 4877
mm, 152 mm)
400 lb
(182 kg)
845 lb
(383 kg)
Indicators 2”
(51 mm)
All Others
18” (457
mm)
-11: red
-21: amber
300 W 120 V AC 2.5 A A1 63
BA-1518
w/TNMC
2 Total
Top
Bottom
H8’-0”, W16’-0”, D6”
(2438 mm, 4877
mm, 152 mm)
H3’-0”, W16’-0”, D6”
(914 mm, 4877 mm,
152 mm)
H5’-0”, W16’-0”, D6”
(1524 mm, 4877
mm, 152 mm
480 lb
(218 kg)
912 lb
(414 kg)
Indicators 2”
(51 mm)
All Others
18” (457
mm)
-11: red
-21: amber
600 W
(w/red
TNMC)
600 W
(w/amber
TNMC)
120 V AC 5.0 A
5.0
A1 63
