Hirschmann/DIN connector code numbers (continued)
Feature S std. float B anodized ramp
Connector 1x4 1x4 1x4 1x4
passive S 157B4833
PVEM 12 V 157B4116 157B4416 157B4516
24 V 157B4128 157B4428 157B4528
PVEO 12 V 157B4216 157B4266 157B4217
24 V 157B4228 157B4268 157B4229
S = super fine hysteresis, 1x4 = one plug four pins
ATEX (24 V) connector code numbers
Cable type S PFOP PFOP PFOP,
cable dir PVB
BFOU
Flying wire 5 m 10 m 5 m 5 m
PVEH passive 11084101 11084109 11084092 11084098
PVES S 11084102 11084110 11084093 11084099
PVEO 11084100 11084108 11084051 11084097
S = super fine hysteresis,
AMP/Deutsch code numbers for PVHC
Connector Code Number
PVHC
AMP
12 V 11112037
24 V 11112036
PVHC
Deutsch
12 V 11112038
24 V 11112039
PVE code numbers for use on PVG 120
AMP code numbers
Feature anodized
Connector 1x4 = one plug x four pins
PVEH active 155G4094
passive 155G4095
PVEO 12 V 155G4282
24 V 155G4284
Hirschmann/DIN code numbers
Feature anodized
Connector 1x4 = one plug x four pins
PVEH active 155G4092
passive 155G4093
PVES passive 11111210
Technical Information PVE, Series 4 for PVG 32/100/120 and PVHC
PVE code numbers
520L0553 • Rev GD • Jan 2014 49
