VLT
®
8000 AQUA
Please note that the matching of the typical Danfoss frequency converter and filter is pre-calculated based on
400 V and assuming typical motor load (4 or 2 pole motor). VLT 8000 is based on a max. 110% torque
application.
The pre-calculated filter current may be different than the input current ratings of VLT 8000 as stated in the
respective operating instructions, as these numbers are based on different operating conditions.
440-480 V, 60 Hz
Danfoss ordering numberI
AHF,N
Typical Motor Used
[HP]
AHF 005 AHF 010
VLT 8000
19 A 10, 15 175G6612 175G6634 8011, 8016
26 A 20 175G6613 175G6635 8022
35 A 25, 30 175G6614 175G6636 8027, 8032
43 A 40 175G6615 175G6637 8042
72 A 50, 60 175G6616 175G6638 8052, 8062
101 A 75 175G6617 175G6639 8072
144 A 100, 125 175G6618 175G6640 8102, 8122
180 A 150 175G6619 175G6641 8152
217 A 200 175G6620 175G6642 8202
289 A 250 175G6621 175G6643 8252
324 A 300 175G6689 175G6692 8302
370 A 350 175G6690 175G6693 8352
Higher ratings can be achieved by p
aralleling the filter units
506 A 450 217 A and 289 A units 8452
578 A 500 Two 289 A units 8502
578 A 550 Two 289 A units 8602
648 A 600 Two 324 A units 8652
Please note that the matching of the Danfoss frequency converter and filter is pre-calculated based on 480 V
and assuming typical motor load. VLT 8000 is based on 110 % torque application.
The pre-calculated filter current may be varying from the input current ratings of VLT 8000 as stated in the
respective operating instructions, as these numbers are based on different operating conditions.
690 V, 50 Hz
IAHF,N Typical motor u sed Ordering no. AHF 005 Ordering no. AHF 010 VLT 8000 110%
43 37, 45 130B2328 130B2293 8052
72 55, 75 130B2330 130B2295 8062, 8072
101 90 130B2331 130B2296 8102
144 110, 132 130B2333 130B2298 8122, 8152
180 160 130B2334 130B2299 8202
217 200 130B2335 130B2300 8252
289 250 130B2331 & 130B2333 130B2301 8302
324 315 130B2333 & 130B2334 130B2302 8352
370 400 130B2334 & 130B2335 130B2304 8402
469 500 130B2333 & 2 x
130B2334
130B2299 & 130B2301 8502
578 560 3 x 130B2334 2 x 130B2301 8602
613 630 3 x 130B2335 130B2301 & 130B2302 8652
MG.83.A2.02 - VLT is a registered Danfoss trademark
24
