■ Tightening torque and screw sizes
The table shows the torque required when fitting
terminals to the frequency converter. For VLT
8006-8032, 200-240 V; VLT 8006-8122, 380-480
and VLT 8002-8072, 525-600 V the cables must be
fastened with screws. For VLT 8042-8062, 200-240
V; VLT 8152-8652, 380-480 V and VLT 8052-8652,
525-690 V, the cables must be fastened with bolts.
These figures apply to the following terminals:
91, 92, 93
Mains terminals (Nos.) L1, L2, L3
96, 97, 98
Motor terminals (Nos.) U, V, W
Earth terminal (Nos.) 94, 95, 99
VLT type
3 x 200-240 V
Tightening-up
torque
Screw/bolt
size
Tool
VLT 8006-8011 16 in-lbs/1.8 Nm (IP 20) M4
VLT 8006-8016 16 in-lbs/1.8 Nm (IP 54) M4
VLT 8016-8027 26.6 in-lbs/3.0 Nm (IP 20) M5
3)
4mm
VLT 8022-8027 26.6 in-lbs/3.0 Nm (IP 54)
2)
M5
3)
4mm
VLT 8032 53 in-lbs/6.0 Nm M6
3)
5mm
VLT 8042-8062 100 in-lbs/11.3 Nm M8 (bolt)
VLT type
3 x 380-480 V
Tightening-up
torque
Screw/bolt
size
Tool
VLT 8006-8011 5.3 in-lbs/0.5-0.6 Nm M3
VLT 8016-8027 16 in-lbs/1.8 Nm (IP 20) M4
VLT 8016-8032 16 in-lbs/1.8 Nm (IP 54) M4
VLT 8032-8052 26.6 in-lbs/3.0 Nm (IP 20) M5
3)
4mm
VLT 8042-8052 26.6 in-lbs/3.0 Nm (IP 54)
2)
M5
3)
4mm
VLT 8062-8072 53 in-lbs/6.0 Nm M6
3)
5mm
VLT 8102-8122 133 in-lbs/15 Nm (IP 20) M8
3)
6mm
213 in-lbs/24 Nm (IP 54)
1)
8mm
VLT 8152-8352 168 in-lbs/19 Nm
4)
M10 (bolt)
5)
16 mm
VLT 8452-8652 168 in-lbs/19 Nm M10 (compression lug)
5)
16 mm
84 in-lbs/9.5 Nm M8 (box lug)
5)
13 mm
VLT type
3 x 525-600 V
Tightening-up
torque
Screw/bolt
size
Tool
VLT 8002-8011 5.3 in-lbs/0.5-0.6 Nm M3
VLT 8016-8027 16 in-lbs/1.8 Nm M4
VLT 8032-8042 26.6 in-lbs/3.0 Nm
2)
M5
3)
4mm
VLT 8052-8072 53 in-lbs/6.0 Nm M6
3)
5mm
VLT type
3 x 525-690 V
VLT 8052-8402 168 in-lbs/19 Nm
4)
M10 (bolt)
5)
16 mm
VLT 8502-8652
525-690 V
168 in-lbs/19 Nm M10 (compression lug)
5)
16 mm
84 in-lbs/9.5 Nm M8 (box lug)
5)
13 mm
1. Loadsharing terminals 14 Nm/M6, 5 mm in Allen key
2. IP 54 units with RFI filter mains terminals 6 Nm
3. Allen screws (hexagon)
4. Loadsharing terminals 84 in-lbs/9.5 Nm/M8 (bolt)
5. Wrench
