VLT
®
8000 AQUA
Installation
■ Mechanical dimensions
All the below listed measurements are in mm/in
VLT type A B C a b aa/bb Type
IP 00/Chassis 200 - 240 V
8042 - 8062 800/31.5 370/14.6 335/13.2 780/30.7 270/10.6 225/8.9 B
IP 00 380 - 480 V
8152 - 8202 1046/41.2 408/16.1 373/14.7
1)
1001/39.4 304/12.0 225/8.9 J
8252 - 8352 1327/52.2 408/16.1 373/14.7
1)
1282/50.5 304/12.0 225/8.9 J
8452 - 8652 1547/60.9 585/23.0 494/19.4
1)
1502/59.1 304/12.0 225/8.9 (aa) I
IP 00 525 - 690 V
8052 - 8202 1046/41.1 408/16 373
1)
/14.7 1001/39.4 304/12 225/8.7 J
8252 - 8402 1327/52.2 408/16 373
1)
14.7 1282/50.4 304/12 225/8.7 J
8502 - 8652 1547/60.9 585/23.0 494/19.4
1)
1502/59.1 304/12.0 225/8.9 (aa) I
IP 20/NEMA 1 200 - 240 V
8006 - 8011 560/22.0 242/9.5 260/10.2 540/21.3 200/7.9 200/7.9 D
8016 - 8022 700/27.6 242/9.5 260/10.2 680/26.8 200/7.9 200/7.9 D
8027 - 8032 800/31.5 308/12.1 296/11.7 780/30.7 270/10.6 200/7.9 D
8042 - 8062 954/37.6 370/14.6 335/13.2 780/30.7 270/10.6 225/8.9 E
IP 20/NEMA 1 380 - 480 V
8006 - 8011 395/15.6 220/8.7 200/7.9 384/15.1 200/7.9 100/3.9 C
8016 - 8027 560/22.0 242/9.5 260/10.2 540/21.3 200/7.9 200/7.9 D
8032 - 8042 70027.6 242/9.5 260/10.2 680/26.8 200/7.9 200/7.9 D
8052 - 8072 800/31.5 308/12.1 296/11.7 780/30.7 270/10.6 200/7.9 D
8102 - 8122 800/31.5 370/14.6 335/13.2 780/30.7 330/13.0 225/8.9 D
IP 21/NEMA 1 380-480 V
8152 - 8202 1208/47.5 420/16.5 373/14.7
1)
1154/45.4 304/12.0 225/8.9 J
8252 - 8352 1588/62.5 420/16.5 373/14.7
1)
1535/60.4 304/12.0 225/8.9 J
8452 - 8652 2000/78.7 600/23.6 494/19.4
1)
- - 225/8.9 (aa) H
IP 20/NEMA 1 525 - 690 V
8002 - 8011 395/15.55 220/8.66 200/7.87 384/15.12 200/7.87 100/3.94 C
8016 - 8027 560/22.05 242/9.53 260/10.23 540/21.26 200/7.87 200/7.87 D
8032 - 8042 700/27.56 242/9.53 260/10.23 680/26.77 200/7.87 200/7.87 D
8052 - 8072 800/31.50 308/12.13 296/11.65 780/30.71 270/10.63 200/7.87 D
IP 21/NEMA 1 525 - 690 V
8052 - 8202 1208/47.5 420/16.5 3731)/14.7 1154/45.4 304/12 225/8.7 J
8252 - 8402 1588/62.5 420/16.5 3731)/14.7 1535/60.4 304712 225/8.7 J
8502 - 8652 2000/78.7 600/23.6 494/19.4
1)
- - 225/8.9 (aa) H
IP 54/NEMA 12 200 - 240 V A B C D a b aa/bb Type
8006 - 8011 810/31.9 350/13.8 280/11.0 70/2.8 560/22.0 326/12.8 200/7.9 F
8016 - 8032 940/37.0 400/15.7 280/11.0 70/2.8 690/27.2 375/14.8 200/7.9 F
8042 - 8062 937/36.9 495/9.5 421/16.6 - 830/32.7 374/14.8 225/8.9 G
IP 54/NEMA 12 380 - 480 V
8006 - 8011 530/20.9 282/11.1 195/7.7 85/3.3 330/13.0 258/10.2 100/3.9 F
8016 - 8032 810/31.9 350/13.8 280/11.0 70/2.8 560/22.0 326/12.8 200/7.9 F
8042 - 8072 940/37.0 400/15.7 280/11.0 70/2.8 690/27.2 375/14.8 200/7.9 F
8102 - 8122 940/37.0 400/15.7 360/14.2 70/2.8 690/27.2 375/14.8 225/8.9 F
8152 - 8202 1208/47.5 420/16.3 373/14.7
1)
- 1154/45.4 304/12.0 225/8.9 J
8252 - 8352 1588/62.5 420/16.3 373/14.7
1)
- 1535/60.4 304/12.0 225/8.9 J
8452 - 8652 2000/78.7 600/23.6 494/19.4
1)
- - 225/8.9 (aa) H
IP 54/NEMA 12 525 - 690 V
8052 - 8202 1208/47.5 420/16.5 373
1)
14.7 1154/45.4 304/12 225/8.7 J
8252 - 8402 1588/62.5 420/16.5 373
1)
/14.7 1535/60.4 304/12 225/8.7 J
8502 - 8652 2000/78.7 600/23.6 494/19.4
1)
- - 225/8.9 (aa) H
1. With disconnect add 44 mm/1.7 in
aa: Minimum space above enclosure
bb: Minimum space below enclosure
MG.83.A2.02 - VLT is a registered Danfoss trademark
51
