Danfoss VLT AutomationDrive FC 301 Operating Guide

8 Specifications
8.1 Electrical Data
8.1.1 Mains Supply 200–240 V
Table 29: Mains Supply 200–240 V, PK25–P3K7
Type designation
PK25
PK37
PK55
PK75
P1K1
P1K5
P2K2
P3K0
P3K7
Typical shaft output [kW/
(hp)], high overload
0.25 (0.34)
0.37 (0.5)
0.55 (0.75)
0.75 (1.0)
1.1 (1.5)
1.5 (2.0)
2.2 (3.0)
3.0 (4.0)
3.7 (5.0)
Enclosure protection rating
IP20 (FC 301 only)
A1
A1
A1
A1
A1
A1
–
–
–
Enclosure protection rating
IP20, IP21
A2
A2
A2
A2
A2
A2
A2
A3
A3
Enclosure protection rating
IP55, IP66
A4/A5
A4/A5
A4/A5
A4/A5
A4/A5
A4/A5
A4/A5
A5
A5
Output current
Continuous (200–240 V) [A]
1.8
2.4
3.5
4.6
6.6
7.5
10.6
12.5
16.7
Intermittent (200–240 V) [A]
2.9
3.8
5.6
7.4
10.6
12
17
20
26.7
Continuous kVA (208 V)
[kVA]
0.65
0.86
1.26
1.66
2.38
2.70
3.82
4.50
6.0
Maximum input current
Continuous (200–240 V) [A]
1.6
2.2
3.2
4.1
5.9
6.8
9.5
11.3
15
Intermittent (200–240 V) [A]
2.6
3.5
5.1
6.6
9.4
10.9
15.2
18.1
24
Additional specifications
Estimated power loss at rat-
ed maximum load [W]
(1)
21
29
42
54
63
82
116
155
185
Efficiency
(2)
0.94
0.94
0.95
0.95
0.96
0.96
0.96
0.96
0.96
1
Applies for dimensioning of drive cooling. If the switching frequency is higher than the default setting, the power losses may increase. LCP and
typical control card power consumptions are included. For power loss data according to EN 50598-2, refer to Danfoss
MyDrive® ecoSmart website.
2
Efficiency measured at nominal current. For energy efficiency class, see
8.4 Ambient Conditions. For part load losses, see Danfoss MyDrive® ecoS-
mart website.
Table 30: Mains Supply 200–240 V, P5K5–P11K
Type designation
P5K5
P7K5
P11K
High/normal overload
(1)
HO
NO
HO
NO
HO
NO
Typical shaft output [kW/(hp)]
5.5 (7.5)
7.5 (10)
7.5 (10)
11 (15)
11 (15)
15 (20)
Enclosure protection rating IP20
B3
B3
B4
Enclosure protection rating IP21, IP55, IP66
B1
B1
B2
Output current
Continuous (200–240 V) [A]
24.2
30.8
30.8
46.2
46.2
59.4
AQ267037727118en-000101 / 130R030060 | Danfoss A/S © 2021.01
Specifications
VLT® AutomationDrive FC 301/FC 302
Operating Guide
