7.4 Error Code List
LCP-related errors are shown in the format of Err XX, where XX indicates the error number. The LCP errors do not aect the
operation of the frequency converter.
LCP error code Description
Err 84 Communication between the LCP and the frequency converter is lost.
Err 85 The LCP key is disabled. One of the LCP keys is disabled in parameter group 0-4* LCP Keypad.
Err 86 Data copy failure: Occurs when data is copied from frequency converter to LCP, or from LCP to frequency
converter (parameter 0-50 LCP Copy).
Err 87 Invalid LCP data: Occurs when data is being copied from LCP to frequency converter (parameter 0-50 LCP Copy).
Err 88 LCP data incompatible: Occurs when data is being copied from LCP to frequency converter (parameter 0-50 LCP
Copy), typically because data is moved between frequency converters that have major software dierences.
Err 89 An operation is issued via LCP to write a value to a parameter that is read-only.
Err 90 LCP, serial communication, or eldbus communication attempts to update the same parameters at the same time.
Err 91 The parameter value that is input via the LCP is invalid.
Err 92 The parameter value that is input via the LCP exceeds limits.
Err 93 The LCP copy operation cannot be conducted when the frequency converter is running.
donE A notication that the LCP Copy process is nished.
NWrun The parameter cannot be changed while the frequency converter is running.
Err. The password that is input via the LCP is incorrect.
Table 7.3 Error Code List
7.5
Troubleshooting
Symptom Possible cause Test Solution
Motor not running
LCP stop Check if [O] has been pressed.
Press [Auto On] or [Hand On]
(depending on operating mode) to
run the motor.
Missing start signal (standby)
Check parameter 5-10 Terminal 18
Digital Input of correct setting for
terminal 18 (use default setting).
Apply a valid start signal to start the
motor.
Motor coast signal active (coasting)
Check parameter 5-12 Terminal 27
Digital Input for correct setting of
terminal 27 (use default setting).
Apply 24 V on terminal 27 or
program this terminal to [0] No
operation.
Wrong reference signal source
Check the following:
The reference signal is local,
remote, or bus reference?
Preset reference is active?
Terminal connection is correct?
The scaling of terminals is correct?
The reference signal is available?
Program correct settings. Set preset
reference active in parameter group
3-1* References. Check for correct
wiring. Check scaling of terminals.
Check reference signal.
Motor is running in
the wrong direction
Motor rotation limit
Check that parameter 4-10 Motor
Speed Direction is programmed
correctly.
Program correct settings.
Active reversing signal
Check if a reversing command is
programmed for the terminal in
parameter group 5-1* Digital inputs.
Deactivate reversing signal.
Wrong motor phase connection
Change parameter 1-06 Clockwise
Direction.
Diagnostics and Troubleshoo... Quick Guide
MG06A702 Danfoss A/S © 03/2017 All rights reserved. 51
