Parameter [Units]
Par. 0-01
Language
Par. 1-20
Motor Power [kW]
[kW]
Par. 1-21
Motor Power [HP]
[HP]
Par. 1-22
Motor Voltage
* [V]
Par. 1-23
Motor Frequency
[Hz]
Par. 1-24
Motor Current
[A]
Par. 1-25
Motor Nominal Speed
[RPM]
Par. 1-28
Motor Rotation Check
[Hz]
Par. 3-41
Ramp 1 Ramp Up Time
[s]
Par. 3-42
Ramp 1 Ramp Down Time
[s]
Par. 4-11
Motor Speed Low Limit [RPM]
[RPM]
Par. 4-12
Motor Speed Low Limit [Hz]
* [Hz]
Par. 4-13
Motor Speed High Limit [RPM]
[RPM]
Par. 4-14
Motor Speed High Limit [Hz]
* [Hz]
Par. 3-19
Jog Speed [RPM]
[RPM]
Par. 3-11
Jog Speed [Hz]
* [Hz]
Par. 5-12
Terminal 27 Digital Input
Par. 5-40
Function Relay
**
Table 6.2: Quick Setup parameters
*The display showing depends on choices made in par. 0-02
Motor Speed Unit
and par. 0-03
Regional Settings
. The default settings of par. 0-02
Motor
Speed Unit
and par. 0-03
Regional Settings
depend on which region of the world the frequency converter is supplied to but can be re-programmed as
required.
** Par. 5-40
Function Relay
, is an array, where one may choose between Relay1 [0] or Relay2 [1]. Standard setting is Relay1 [0] with the default choice
Alarm [9].
See the parameter description in the section
Commonly Used Parameters
.
For a detailed information about settings and programming, please see the
VLT HVAC Drive Programming Guide, MG.11.CX.YY
x=version number y=language
NB!
If [No Operation] is selected in par. 5-12
Terminal 27 Digital Input
, no connection to +24 V on terminal 27 is necessary to enable start.
If [Coast Inverse] (factory default value) is selected in par. 5-12
Terminal 27 Digital Input
, a connection to +24V is necessary to enable
start.
0-01 Language
Option: Function:
Defines the language to be used in the display. The frequency converter can be delivered with 4
different language packages. English and German are included in all packages. English cannot be
erased or manipulated.
[0] * English Part of Language packages 1 - 4
[1] Deutsch Part of Language packages 1 - 4
[2] Francais Part of Language package 1
[3] Dansk Part of Language package 1
[4] Spanish Part of Language package 1
[5] Italiano Part of Language package 1
Svenska Part of Language package 1
[7] Nederlands Part of Language package 1
6 How to Programme the Low Harmonic Drive
VLT HVAC Low Harmonic Drive Operating In-
structions
86 MG.16.A1.02 - VLT
®
is a registered Danfoss trademark
