Dantherm calorex WA 1234BC User Manual

POOL WATER SCHEMATIC (STANDARD)
ENSURE POOL FILTRATION PUMP SELECTION ALLOWS FOR ALL SYSTEM RESISTANCE
FILTER
PUMP
POOL
NON
RETURN
VALVE OR
LOOP
VALVE C
BYPASS VALVE
(LOCKING GATE
VALVE TYPE)
AUX
HEATER
IF FITTED
SANITISER OR
CHEMICAL DOSING
POSITION AFTER
CALOREX
ISOLATING
VALVE
'B'
CALOREX
ISOLATING
VALVE
' A'
CALOREX
RR?›Nfi“fl
RR
cSRUWTQ?hrr?R
MAINS WATER
FEED
TO DOMESTIC COLD WATER SERVICES
EXISTING COLD WATER STORAGE TANK (INSULATED)
UP TO 500 LITRES CAPACITY
CALOREX WATER CHILLER
CIRCULATING
PUMP
RECOMMENDED INSTALLATION OF CALOREX CHILLER TO COOL DOMESTIC WATER
ALTERNATIVE INSTALLATION OF CALOREX CHILLER TO BE CONSIDERED WHEN EXISTING
STORAGE TANK IS INADEQUATELY INSULATED OR LARGER THAN 500 LITRES CAPACITY
CALOREX
RR?›Nfi“fl
RR
cSRUWTQ?hrr?R
MAINS WATER
FEED
TO DOMESTIC
COLD WATER
SERVICES
EXISTING COLD WATER STORAGE TANK
CALOREX WATER CHILLER
CIRCULATING
PUMP
VENT
FILL
BUFFER TANK (DIRECT TYPE)
NOMINAL CAPACITY 125-250 LITRES
FLOW
SETTING
FLOW METER
METHOD
FLOW
SETTING
PRESSURE
GAUGES
METHOD
5. WATER SCHEMATICS
14
SD331852 ISSUE 7
OWNER INSTALLATION MANUAL 634ACH/ACL/AHC /1222AC/1234BC/BHC /1834BHC /PP22BC

Dantherm calorex WA 1234BC Specifications

General

Brand	Dantherm
Model	calorex WA 1234BC
Category	Heat Pump
Language	English
