ELECTRICAL
ELECTRICAL (MACHINE WIRING AND SUPPLY)
SEE FIG. 4,5,6 AND 7 FOR PREFERRED METHOD
Use of e Danerm Ltd. Energy Management Controller will enable greater
savings to be made because e circulating pump need only run when required
and is can be at a time preferred by e Customer, i.e. in e Economy 7
period.
All electrical work to be carried out in accordance wi l.E.E. standards, latest
issue, or local codes of practice as applicable.
The machine should be installed in accordance wi EMC2004/108/EC.
Protected supply to incorporate fuses or motor type circuit breakers (Type C)
to specified rating, (see Data Sheet). H.R.C. fuses are recommended. An isolator
which disconnects all poles must be fitted wiin 2m and in sight of machine.†
All units must be correctly eared/grounded. An ear leakage trip of e
current operating type (30mA) is recommended to be fitted to is heat pump
and any associated equipment. When fitting recommended ear leakage trip,
to avoid nuisance tripping, e machine should be connected to its own 30mA
trip separate from any oer associated equipment.
INCONSISTENT ELECTRICAL SUPPLY
The following limits of operation must not be exceeded if Danerm Ltd.
machines are to be guaranteed eier in performance or warranty terms:
NOTE: 1234BC/1834BHC and PP22BC units are fitted wi phase
protection and will not run if e phases are not connected in correct
order (phase sequence) or if e supply voltage is 15% less an e
nominal voltage. (415V for 3~N 50Hz) . The lamp on e phase rotation
relay, situated in e electric box, is illuminated when e phases are
correctly connected and e voltage is sucient.
Minimum Maximum
Voltage
Single phase machines 207V 253V
Three-phase machines 360V 440V
Cycle frequency 47.5Hz 52.5Hz
N.B. This voltage must be available at e heat pump whilst running.
† Note e isolator must have a minimum of 3mm air gap when turned off.
17
SD331852 ISSUE 7
