HEAT PUMPS FOR POOLS. SPECIALIST APPLICATIONS - CHILLERS, HEATERS AND HEATER CHILLERS
DATASHEETS
Model Units
AW634AHC WA634ACH/ACL WA1222AC/
WA1234BC
AW1234BHC AW1834BHC
Performance
Water heating mode
Ambient 10°C, water 30°C kW 3.39 n/a n/a 8.7 12.0
Ambient 30°C, water 30°C kW 6.6 n/a n/a 13.0 16.0
Water cooling mode
Ambient 10°C, water 15°C kW 5.3 5.3 9.0 9.0 11.4
Ambient 45°C, water 15°C kW 3.4 3.4 7.0 7.0 8.8
Electrical
Total power consumed
Water heating mode
Ambient 10°C, water 30°C kW 1.31 n/a n/a 2.0 2.7
Ambient 30°C, water 30°C kW 1.46 n/a n/a 2.3 3.1
Water cooling mode
Ambient 10°C, water 15°C
kW 1.5 1.5 1.7 1.7 2.2
Ambient 45°C, water 15°C
kW 1.8 1.8 2.6 2.6 3.5
Min supply capacity (Max F L A) I ph N
A 12 12 23.9 n/a n/a
Min supply capacity (Max F L A) 3 ph N
A n/a n/a 10.5 17.1 9.2
Max supply fuse 1 ph N
A 20 20 35 n/a n/a
Max supply fuse 3 ph N
A n/a n/a 16 25 16
Water flows etc.
Water flow rate
L/minute 33 33 33 33 42
Water pressure drop at rated flow
metres hd 1.4 1.4 7.0 7.0 3.5
Max working pressure water
bar 3.5 3.5 3.5 3.5 3.5
Water connections
inches 3/4 BSPM 1.5” BSPM
Condensate drain connections
inches 3/4 domestic waste 1.5” BSPM
Compressor
Nominal power consumed
kW 1.4 1.4 3.4 3.4 3.2
LRA- 1phN
A 42 42 100 N/A N/A
RLA- 1phN
A 9 9 16.6 N/A N/A
So start amps 1 ph N A 23 23 34 N/A N/A
LRA- 3phN A n/a n/a 48 48 48
RLA.-3phN A n/a n/a 7.3 7.9 10
So start amps 3 ph N A n/a n/a 17 25 25
Main fan
Air flow Anemometer ~ air on grille, dry evaporator
m³/h 2400 2400 3200 3200 4300
Max external static pressure
mmWg 0 0 0 0 4
FLA- 1ph N
A 2.2 2.2 3.8 3.8 N/A
FLA- 3ph N
A N/A N/A N/A N/A 1.65
Physical dimensions
Wid un-packed
mm 820 820 1060 1060 980
Dep un-packed
mm 702 702 705 705 700
Height un packed
mm 762 762 807 807 1490
Weight un-packed kg 111 111
150 157 230
Sound pressure levels at 3 metres dbA 63 63 71 71 61
For Accurate Application Sizing Consult Danerm Ltd
1mm WG = 9.8 Pa
NOTES
1) Weight and dimensions nett 1mm WG = 9.8 Pa
2) Performance design limitations 1m hd =1.4 psi
Water heating mode: Ambient = 10°C min 50°C max. Note: WA634ACL 0ºC min 35ºC max 1L/min = 0.22 gall/min
Water = 10°C min 50°C max
Water cooling mode: Ambient = 10°C min 50°C max. Note: WA1222AC 10ºC min 40ºC max
Water = 10°C min 35°C max
3) Pool water to have correct balance, pH 7.2 - 7.8. Free Chlorine 1.0 - 2.0 ppm domestic, 3.0 - 6.0 commercial.
4) Allow 500mm clearance to service panels
5) Danerm Ltd. reserves e right to change or modify models wiout prior notice
6) Global warming potential (GWP) R407c 1774, R134a 1430
39
SD331852 ISSUE 7
