INSTALLATION
If using the adhesive strips:
a.
Carefully clean the adhesive strip
seats of
the base to remove any
impurities that could reduce
adhesion.
b. Remove the protective plastic from
one side of the adhesive strips and
stick them onto the base surface.
c. Remove the plastic from the other
side of the strips and affix the base
to the wall as indicated in the figure
below.
If using the mounting screws:
3.
Using the mounting holes on the
base as a pattern, mark the wall
where you desire to mount the BC-
80X0/C-8000.
4. Drill the appropriate size holes and
insert the threaded dowels (not
provided) into the holes.
5. Position the base on the wall as
indicated in the figure below and
affix it by means of the screws (not
provided).
Inclined Base Wall-mounting
6. Attach the cradle on the base by sliding it along the mounting tabs until aligned.
7. If mounting the BC-80X0 cradle, insert the antenna in the appropriate hole on
the body of the cradle and screw it clockwise until tight.
