Connecting the Base Station
6 QuickScan™ QBT21X1
Most connections plug directly into the host device as shown
in Figure 4. Keyboard Wedge interface cables have a ‘Y’ con-
nection where its female end mates with the male end of the
cable from the keyboard and the remaining end at the key-
board port on the terminal/PC.
Figure 4. Connecting to the Host
Power Connection —
Plug the AC Adapter into an approved AC
socket. If plugged into the wall, ensure cable is facing down-
wards (as shown in Figure 3) to prevent undue strain on the
socket.
System and Network Layout
Typical Setup with Cradle and Host
Figure 5. Reader Layout
U
S
B
K
e
y
b
o
a
r
d
W
e
d
g
e
or...
Reader
Base Station
Host
Power Supply
