$CADOT06(CR)

Optional Add-on Timer = 60ms

$CADOT07(CR)

Optional Add-on Timer = 70ms

DEFAULT

$CADOT0A(CR)

Optional Add-on Timer = 100ms

$CADOT0C(CR)

Optional Add-on Timer = 120ms

$CADOT0E(CR)

Optional Add-on Timer = 140ms

$CADOT10(CR)

Optional Add-on Timer = 160ms

1D Symbologies Enter/Exit Programming Mode

Product Reference Guide

105

Optional Add-On Timer (continued)

Default Chapter3
