Datalogic QuickScan QBT2430 User Manual

Quick Reference Guide iii
DATALOGIC IP TECH S.R.L.
END USER SOFTWARE LICENSE AGREEMENT (EULA)
FOR THE QuickScan™ QBT2400 PRODUCT SERIES
Notice to End User: There are two types of software covered by this END USER
LICENSE AGREEMENT ("EULA"): (1) The Datalogic Product you have acquired con-
tains embedded software ("Embedded Software") which is integral to the Product's
operation; and (2) Optional Application Software provided to you on an optional
basis ("Application Software"). Embedded Software and Application Software are
collectively referred to as "Software" and are subject to the terms and conditions
contained in this EULA. Software is provided only for use with, and for authorized
end users of, the Datalogic QuickScan™ QBT2400. Portions of the Embedded Soft-
ware include or operate with Open Source software or libraries ("Open Source").
Use of Open Source is subject to the Open Source licenses available at the follow-
ing website: http://www.datalogic.com/oss.
This EULA (End User Software License Agreement) ("EULA” or "Agreement") is a
legally binding agreement governing the licensing of the Software and Documen-
tation by Datalogic IP Tech S.r.l. and its subsidiaries and affiliates ("Datalogic") to
the entity or person who has purchased or otherwise acquired a Datalogic Product
("End User"). For purposes of this Agreement, any software that is not Embedded
Software or Application Software is software associated with a separate end-user
license agreement is licensed to you under the terms of that license agreement.
Datalogic and End User hereby agree as follows:
1. Definitions.
1.1 "Affiliate" means a business entity currently existing or later acquired that is
controlled by, or is under common control with Datalogic S.p.A.
1.2 "Documentation" means materials such as user's guides, program reference
guides, quick reference guides, manuals, or similar materials associated with
or related to the Datalogic Product, whether in printed, "online", or other form.
1.3 "Proprietary Information" means: (a) source code, object code, software, docu-
mentation, and any related internal design, system design, data base design,
algorithms, technology, technical data or information, implementation tech-
niques, and trade secrets related to the Software, (b) any other trade secrets
marked appropriately or identified as proprietary or confidential, and (c) any
information that End User, under the circumstances, should recognize as con-
fidential. Proprietary Information does not include any information that the
receiving party can establish was (1) in the public domain, (2) already in the
receiving party's possession or rightfully known prior to receipt, (3) rightfully
learned from a third party not in violation of any other's proprietary rights, or
(4) independently developed without access to Proprietary Information.
1.4 "Datalogic Product" means the Datalogic QuickScan™ QBT2400 series scanner
product, including all embedded Software in and all Documentation related to
such product, which has been purchased or otherwise acquired by End User,
whether obtained directly or indirectly from Datalogic.
1.5 "Software" means any software or computer programs of Datalogic or its third
party licensors in machine readable form which is embedded in the Datalogic
Product, whether obtained directly or indirectly from Datalogic, including any
replacement, update, upgrade, enhancement or modification.
2. Scope Of License Granted.
2.1 Datalogic grants to End User a personal non-exclusive, non-transferable, per-
petual license to use the Software, solely on the Datalogic Product in which it
is embedded ("designated Datalogic Product"), in machine-readable form only,
solely for End User's internal business purposes. This Agreement does not
convey ownership of the Software to End User. Title to the Software shall be
and remain with Datalogic or the third party from whom Datalogic has
obtained a licensed right. As used in this Agreement, the term "purchase" or
its equivalents when applied to the Software shall mean "acquire under
license." End User is not entitled to receipt or use of the source code to any
Software.
2.2 End User shall not copy, modify, decompile, disassemble, reverse engineer, or
otherwise reproduce or remanufacture the Software, whether modified or
unmodified, nor sell, assign, sublicense, distribute, lend, rent, give, or otherwise
transfer the Software to any other person or organization, for purposes other
than as expressly provided in this Agreement, without Datalogic's prior written
consent.
3. Transfers, Support.
3.1 Any copying, installing, reproduction, remanufacture, reverse engineering,
electronic transfer, or other use of the Software on other than the designated

Datalogic QuickScan QBT2430 Specifications

General

Connectivity	Bluetooth
Print Contrast Ratio (Minimum)	25%
Humidity	5% to 95% non-condensing
Type	Handheld
Operating Temperature	0°C to 50°C
Drop Resistance	1.5 m
Light Source	LED
Scan Rate	100 scans/sec
Decode Capability	1D, 2D
Radio Range (Open Air)	Up to 100 m
Battery	Li-ion
Interface	USB, RS-232
Supported Barcodes	UPC, EAN, Code 39, Code 128, QR Code, Data Matrix

Summary

Product Description and Features

Omni-Directional Operation

Reader operates omni-directionally; orientation is not important for symbol reading.

Decoding Capabilities

Reliably decodes all standard 1D and 2D bar codes, sending data rapidly to the host.

Setting Up the Reader

Reader Locking Mechanism

Base station provides a locking mechanism to ensure electrical contact between reader and base.

Connecting the Base Station

Base Station Connection and Routing

Steps to connect the base station, including cable routing and power connection.

System and Network Layout

Illustrates a typical setup with the reader, base station, and host device.

Base Station and Battery Management

Radio Base LED Indicators

Explains the meaning of LED indicators on the QuickScan Base for power and charging.

Battery Charging Procedures

Details on how to charge the reader's battery using the base or micro-USB.

Replacing the Battery Pack

Step-by-step instructions for safely removing and installing a battery pack.

Linking the Reader to the Base

RF Device Linking

Procedure to link Datalogic RF devices to the base station.

Bluetooth Adapter Linking (Serial Port)

Steps to link the reader to a Bluetooth adapter using Serial Port Profile mode.

Bluetooth Adapter Linking (HID Mode)

Steps to link the reader to a Bluetooth adapter using HID mode.

Variable PIN Code Configuration

Guidance on configuring a Variable PIN Code for Bluetooth connections.

Reader Programming

Using Programming Bar Codes

How to use programming bar codes to reconfigure the reader's settings.

HID Alt Mode Configuration

Configuring the HID Alternate Mode feature for the reader.

Reader Configuration Settings

Country Mode Settings

Setting the country/language for the keyboard interface and base.

Caps Lock State Configuration

Specifies how the reader sends character data, affecting case sensitivity.

Base Interface Type Selection

Interface Selection Options

Lists the host interfaces supported by the base station.

Keyboard Interface Configuration

Programming bar codes for configuring various USB and Keyboard Wedge interfaces.

Scancode Table Configuration

Information on control character emulation for keyboard interfaces.

Reading Parameters and Aiming

Numlock Setting for Keyboard Interface

Specifies the Numbers Lock setting for keyboard wedge interfaces.

Good Read Green Spot Duration

Configures the duration of the good read green spot indicator after a successful scan.

Scan Modes and Pick Mode

Scan Mode Types

Overview of different scanning modes like Trigger Single, Always On, and Stand Mode.

Pick Mode Configuration

Enables/disables acknowledgment of barcodes not within the aiming pattern.

Multiple Labels in a Volume

Enables/disables the ability to decode multiple labels in a single image.

Technical Specifications

Physical and Electrical Characteristics

Details on physical dimensions, weight, battery type, and charging times.

Performance Characteristics

Information on light source, angles, field of view, and depth of field.

Decode Capability

Lists all supported 1D and 2D barcode symbologies.

User Environment and Radio Features

Specifications for operating conditions, regulatory, and radio frequency.

LED and Beeper Indications

Reader Status Indicators

Explains reader beeps and LED illuminations for functions and errors.

Programming Mode Indications

Indications specific to when the reader is in programming mode.

Error Codes and Base Station Status

Reader Error Code Interpretation

Interprets LED flashes/beeps to identify reader errors and corrective actions.

Base Station LED Indications

Details LED indications for base station status like power, programming, and charging.

Datalogic Limited Factory Warranty

Warranty Coverage and Claims Process

Details warranty coverage, claims process, and exclusions for the product.

Risk of Loss and Assignment

Customer responsibilities regarding product transit risk and warranty assignment.

Ergonomic Use and Cleaning

Ergonomic Usage Guidelines

Recommendations to minimize the risk of ergonomic injury during product use.

Product Cleaning Procedures

Instructions for safely cleaning the scanner and base station surfaces and contacts.

Online Support and Resources

Accessing Datalogic Support

Guide to accessing technical support, downloads, and repair programs via the website.

Hex-Numeric Keypad for Configuration

Numeric and Alpha Entry Bar Codes

Bar codes for entering numbers and characters using a keypad layout.

HID Variable PIN Code Entry

Instructions for using the keypad to enter variable PIN codes for HID connections.
