Datalogic QuickScan QS2500 User Manual

6 QS2500
Numeric Key: If your application accepts only keypad numeric code, use
setting
01 to make the QS2500 output code as numeric-keypad presses
when it reads digits. If you use setting
02, the scanner will send the three
digit ACSCII number for all data using the Alt and numeric keypad key-
codes. Setting
02 prevents the caps Lock from affecting scanner data.
Caps Lock: By selecting Caps Lock or No Caps Lock, the QS2500 can get
Caps Lock status.
Power-On Simulation: All PCs check the keyboard status during the power-
on selftest. It is recommended that you enable this function if you are
working without a keyboard installation. It simulates keyboard timing and
passes the keyboard status to the PC during power-on.
Intercharacter Delay: This delay is inserted after each data character trans-
mitted. If the transmission speed is too high, the system may not be able
to receive all characters. You may need to adjust the delay to make the sys-
tem work properly.
Block Transmission Delay: This is a delay timer between bar code data out-
puts. The feature is used to transfer continually with shorter bar code data
or multifield scanning.

Datalogic QuickScan QS2500 Specifications

General

Wavelength	660 nm
Maximum scan area	102/127 mm
Yaw reading angle	-75 - 75 °
Decoding standards	UPC A, E / EAN 8, 13 / JAN 8, 13, Code 128, Code 93, Pharmacode 39, Code 39, Codabar, Interleaved 2 - 5, Industrial 2 - 5, Matrix 2 - 5, GS1 DataBar, UK/Plessey, MSI/Plessey, Code 16K, Telepen, PDF-417, Code 11
Pitch reading angle	-60 - 60 °
Input voltage	5 V
Power consumption	250 mA
Dimensions (WxDxH)	74 x 114 x 185 mm
Certification	UL, cUL, FCC-A, EN 55022-B, VCCI-A, IEC 60825 Class 1 LED, EU RoHS
Product color	Gray
Storage temperature (T-T)	-30 - 65 °C
Operating temperature (T-T)	0 - 45 °C
Operating relative humidity (H-H)	5 - 95 %

Weight and Dimensions

Weight	179 g
