Datalogic QuickScan QS2500 User Manual

Product Reference Guide 27
Symbology Settings
UPC-A
Read: Format:
Checksum Transmission: With this option enabled, the QS2500 will trans-
mit the checksum.
Truncate Leading/Ending: The leading or ending digits of bar code data
characters can be truncated. The QS2500 will beep instead of reading
anything when the truncate value is more than the bar code data digits or
the truncate leading value overlaps the truncate ending value.
Code ID Setting: The code ID represents the bar code type. It is affixed to
the beginning or end of the transmitted data if the feature is selected. If
you want your application to transmit the code ID, you must set the code
ID transmission option to
01 first. See page 26.
Insertion Group Selection: The QS2500 offers one or two insertion groups
for a symbology. Set one or two digits to indicate which insertion group
you desire. See pages
22–24 for information about insertion groups.
Examples: Group 2  set 02 or 20
Group 1 and 4
 set 14 or 41
Supplement Digits: Are the supplemental 2 or 5 characters for WPC code.
Format
:
Truncate Leading Zero: The 13th digit (always a zero) can be truncated.
Examples: Bar code: “0462531256712”
Output: “462531256712”
Expanding to EAN13: Expands a UPC bar code by adding a leading zero
and sending it to the host in EAN13 format.
Leading Zero Data Digits (11 Digits) Check Digit
Leading Zero Data Digits (11 Digits) Check Digit
Supplemental Digits
(2 or 5)

Datalogic QuickScan QS2500 Specifications

General

Wavelength	660 nm
Maximum scan area	102/127 mm
Yaw reading angle	-75 - 75 °
Decoding standards	UPC A, E / EAN 8, 13 / JAN 8, 13, Code 128, Code 93, Pharmacode 39, Code 39, Codabar, Interleaved 2 - 5, Industrial 2 - 5, Matrix 2 - 5, GS1 DataBar, UK/Plessey, MSI/Plessey, Code 16K, Telepen, PDF-417, Code 11
Pitch reading angle	-60 - 60 °
Input voltage	5 V
Power consumption	250 mA
Dimensions (WxDxH)	74 x 114 x 185 mm
Certification	UL, cUL, FCC-A, EN 55022-B, VCCI-A, IEC 60825 Class 1 LED, EU RoHS
Product color	Gray
Storage temperature (T-T)	-30 - 65 °C
Operating temperature (T-T)	0 - 45 °C
Operating relative humidity (H-H)	5 - 95 %

Weight and Dimensions

Weight	179 g
