22 QS2500
Label Editing (includes Prefix/Suffix)
Prefix Characters: Up to 22 ASCII characters may be sent before data.
Suffix Characters: Up to 22 ASCII characters may be sent after data.
Preamble/Postamble Characters: These characters are affixed to the data
automatically when each bar code is decoded.
Example: Add a prefix/suffix or preamble/postamble for all symbologies. In
this example, you can send a ‘$’ symbol as a prefix for all symbologies by
completing the following steps:
1. Scan the Start Program and Prefix Characters Setting bar codes
below.
2. Use the ASCII code table (see Appendix C - page
66) to find the
ASCII value for $(24
hex
).
3. Scan the bar codes for 2 and 4 on the inside back cover of this man-
ual.
4. Scan the Store Settings bar code on the inside back cover.
5. Scan the Exit bar code.
Insert G1/G2/G3/G4 Character Setting: The QS2500 offer four positions and
four characters to insert into the symbol data.
Example: Bar code: “1 2 3 4 5 6”.
Output: “1 2 A B 3 4 C D 5 6”.
1. Scan Start Program and Insert G1 Characters Setting bar code
below.
2. Use the ASCII code table (see Appendix C on page
66) to find the
ASCII value for A (41) and B (42).
3. Scan the
hex
digit bar codes for 4, 1 and 4, 2 on the inside back cover
of this manual.
Prefix Data Suffix
To Next Page
