Datalogic QuickScan QS2500 User Manual

Product Reference Guide 13
IBM Interface (46XX/USB)
The next few pages contain the programming labels for configuring the
IBM interface to match your interface configuration and symbology spe-
cific requirements.
These bar codes to select the IBM USB interface.
Start Program
Option Bar Code Option
Alphanumeric
Entry
IBM 46xx port 17 00
IBM 46xx port 5B 01
IBM 46xx port 9B 02
Exit
Start Program
Option Bar Code Option
Alphanumeric
Entry
Select IBM Interface
IBM USB 03
Exit

Datalogic QuickScan QS2500 Specifications

General

Wavelength	660 nm
Maximum scan area	102/127 mm
Yaw reading angle	-75 - 75 °
Decoding standards	UPC A, E / EAN 8, 13 / JAN 8, 13, Code 128, Code 93, Pharmacode 39, Code 39, Codabar, Interleaved 2 - 5, Industrial 2 - 5, Matrix 2 - 5, GS1 DataBar, UK/Plessey, MSI/Plessey, Code 16K, Telepen, PDF-417, Code 11
Pitch reading angle	-60 - 60 °
Input voltage	5 V
Power consumption	250 mA
Dimensions (WxDxH)	74 x 114 x 185 mm
Certification	UL, cUL, FCC-A, EN 55022-B, VCCI-A, IEC 60825 Class 1 LED, EU RoHS
Product color	Gray
Storage temperature (T-T)	-30 - 65 °C
Operating temperature (T-T)	0 - 45 °C
Operating relative humidity (H-H)	5 - 95 %

Weight and Dimensions

Weight	179 g
