Datamax DMX E E-4204 - Media;Ribbon; Communications; Fonts; Embedded Bar Codes

54 E-4203/E-4204/E-4304
Media/Ribbon
Media Types Roll-Fed, Die-Cut, Continuous, Fan-Fold
Max. Media Width 4.3" (109.2 mm)
Min. Media Width 1" (25.4 mm)
Max. Print Width 4.09" (104 mm)
Print Length Range .375 - 24" (9.52-609.6 mm)
Media Thickness
Range
.0025 - .01" (.064 mm - .254 mm); up to .007”
(.117 mm) with optional Cutter
Media Supply Roll
Capacity
E-4203:
4" (101.6 mm) O.D. on 1" (25.4 mm) core
E-4204 & E-4304:
5" (127.0 mm) O.D. on 1" (25.4 mm) core
Ribbon Width Range
1.0 - 4.3" (25 - 110 mm)
Ribbon Roll Capacity Matched to media: approx. 361’ (110 m) long
with a 1.5 inch (38 mm) O.D. on a .5 inch core
Communications
Interface USB, RS-232 (DB-9), and Centronics Parallel
Baud Speed 600 to 38,400 bits per second (BPS)
Handshaking Xon/Xoff, CTS, DTR
Parity Even, Odd, or None
Stop Bits 1 or 2
Data Bits 7 or 8
Fonts
9 Bit Map Fonts; rotated 0, 90, 180, 270 degrees.
Embedded Bar Codes
Code 39, Interleaved 2 of 5,Code 128 A, B & C, Codabar, LOGMARS, UPC-A,
UPC-E, UPC 2&5, EAN-8, EAN-13, EAN 2&5, UPC Random Weight, Code 93,
Plessey, USCS, Code 128 MOD 43, Postnet, Uss/EAN-128 Random Weight,
Telepen, UPS Maxicode, PDF417, DataMatrix, Aztec, QR Code, MicroPDF417,
and TLC39
