Replacing the display bezel
NOTE: Before working inside your computer, read the safety information that shipped with your computer and follow the steps
in Before working inside your computer. After working inside your computer, follow the instructions in After working inside your
computer. For more safety best practices, see the Regulatory Compliance home page at www.dell.com/regulatory_compliance.
Topics:
• Procedure
• Post-requisites
Procedure
1. Place the display assembly on a clean and flat surface.
2. Connect the logo-board cable to the logo board.
3. Adhere the tape that secures the logo-board cable to the logo board.
4. Slide the alien head logo-board cable into the logo board and close the latch to secure the cable.
5. Carefully turn the display bezel over.
6. Align the display bezel with the display back-cover and antenna assembly and gently snap the display bezel into place.
Post-requisites
1. Replace the
display assembly.
2. Replace the system board.
3. Replace the heat-sink assembly.
4. Replace the battery.
5. Replace the
coin-cell battery.
6. Replace the computer base.
7. Replace the rear-I/O cover.
8. Replace the memory modules.
9. Replace the solid-state drive.
10.Replace the
wireless card.
11. Replace the base cover.
56
