Replacing the display panel
NOTE: Before working inside your computer, read the safety information that shipped with your computer and follow the steps
in Before working inside your computer. After working inside your computer, follow the instructions in After working inside your
computer. For more safety best practices, see the Regulatory Compliance home page at www.dell.com/regulatory_compliance.
Topics:
• Procedure
• Post-requisites
Procedure
1. Slide the display cable into the connector on the display panel and close the latch to secure the cable.
2. Adhere the tape that secures the display cable to the display panel.
3. Turn the display panel over and gently place it on the display back-cover.
CAUTION: Ensure that no cables are under the display panel.
4. Align the screw holes on the display panel with the screw holes on the display back-cover and antenna assembly.
5. Replace the four screws (M1.6x2) that secure the display panel to the display back-cover and antenna assembly.
Post-requisites
1. Replace the camera.
2. Replace the
display bezel.
3. Replace the display assembly.
4. Replace the system board.
5. Replace the battery.
6. Replace the
heat-sink assembly.
7. Replace the coin-cell battery.
8. Replace the computer base.
9. Replace the rear-I/O cover.
10.Replace the memory modules.
11. Replace the
solid-state drive.
12. Replace the wireless card.
13. Replace the base cover.
64
