Service Manual

2. E1709W Disassembly Block

Screw,P,Cross,

T,T-2*3,BLK*1

(P,Cross,M4*10,BLACK-NL)*2

LE19D5 DISASSEMBLY BLOCK

FINAL ASSY*1

PANEL ASSY*1

BACK COVER ASSY*1

FRONT BEZEL ASSY*1

Rubber Foot *2 For CMO

front bezel*1

logo plate*1

Power -button *1

shield EMI LP2207*5

chassis*1

CHASSIS ASSY*1

(I,Cross,M3*4,Zn-Cc)*4

TAPE ACE 85x20mm LE1913*1

insulator mylar panel*1

panel*1

(P,Cross,W/WAS,M3*6,Zn-Cc)*3

(B,Cross,W/W-SPR,M3*9,Zn)*1

(I,Cross,M3*6,Zn-Cc)*3

power board*1

(P,Cross,W/WAS,M3*6,Zn-Cc)*2

(BOLT,#4-40,NI)*4

FFC-CABLE*1

I/F board*1

insulator mylar chassis02*1

STAND ASSY*1

(P,Cross,M4*10,BLACK-NL)*2

Power-button keyapd*1

kensington lock*1

back cover*1

OSD button *1

Note: 1. The arrows point out the direction of disassembly.
