Dell E2220H User Manual

24 │ About your monitor
Power Management Modes
If you have VESA’s DPM™ compliance display card or software installed in your PC,
the monitor can automatically reduce its power consumption when not in use. This
is referred to as Power Save Mode. If the computer detects input from the
keyboard, mouse, or other input devices, the monitor automatically resumes
functioning. The following table shows the power consumption and signaling of this
automatic power saving feature.
E1920H
VESA Modes
Total Energy Consumption(TEC)
Power
indicator
Power
consumption
Video
Vertical
sync
Horizontal
sync
Normal operation White
13.8 W (maximum)
**
10 W (typical)
ActiveActive Active
Active-o mode White
(Glowing)
Less than 0.3 W
Blanked Inactive Inactive
Switch-o O
7.85 W
24.81 kWh
Less than 0.3 W--
Power Consumption P
on
-
E2020H
E2220H
VESA Modes
VESA Modes
Total Energy Consumption(TEC)
Total Energy Consumption(TEC)
Power
indicator
Power
indicator
Power
consumption
Power
consumption
Video
Video
Vertical
sync
Vertical
sync
Horizontal
sync
Horizontal
sync
Normal operation
Normal operation
White
White
14 W (maximum)
**
11 W (typical)
18 W (maximum)
**
13 W (typical)
Active
Active
Active
Active
Active
Active
Active-o mode
Active-o mode
White
(Glowing)
White
(Glowing)
Less than 0.3 W
Less than 0.3 W
Blanked
Blanked
Inactive
Inactive
Inactive
Inactive
Switch-o
Switch-o
O
O
9.37 W
11.21 W
29
.75 kWh
35.16 kWh
Less than 0.3 W
Less than 0.3 W
-
-
-
-
Power Consumption P
on
Power Consumption P
on
-
-

Dell E2220H Specifications

General

Screen Size	21.5 inches
Resolution	1920 x 1080 (Full HD)
Panel Type	TN
Aspect Ratio	16:9
Refresh Rate	60 Hz
Brightness	250 cd/m²
Contrast Ratio	1000:1
Ports	1 x VGA, 1 x DisplayPort 1.2
Power Consumption	18W (typical)
Response Time	5 ms
Viewing Angle	170° (H) / 160° (V)

Summary

About Your Monitor

Package Contents

Lists included monitor components and accessories.

Product Features

Details the technical specifications and capabilities of the monitor models.

Identifying Features and Controls

Identifies and describes monitor buttons, ports, and labels.

Monitor Specifications

Provides detailed technical specifications for various monitor models.

Electrical Specifications

Outlines electrical input requirements and characteristics for each monitor.

Physical Characteristics

Details physical dimensions, weight, and stand dimensions for each model.

Environmental Characteristics

Lists operating and non-operating temperature, humidity, and altitude limits.

Power Management Modes

Explains power consumption in different VESA modes and energy saving features.

Setting Up The Monitor

Connecting the Stand

Provides step-by-step instructions for attaching the monitor stand.

Connecting Your Monitor

Guides on connecting video cables from the monitor to the computer.

Organizing Cables

Instructions on using the cable management slot for tidy routing.

Removing the Stand

Details the procedure to detach the monitor stand from the display.

Wall Mounting (Optional)

Explains how to mount the monitor on a wall using a compatible kit.

Operating Your Monitor

Turning On The Monitor

Simple instruction on how to power on the monitor.

Using The Front Panel Controls

Describes the function of each control button on the monitor's front panel.

OSD Controls

Explains the function of OSD buttons for image adjustment.

Using the On-Screen Display (OSD) Menu

Guides on navigating and using the monitor's On-Screen Display menu.

Setting Display Resolution

Provides steps to set the optimal display resolution in Windows.

Troubleshooting

Self-Test

Explains how to perform a self-test to check monitor functionality.

Built-in Diagnostics

Details how to run the monitor's built-in diagnostic tool for troubleshooting.

Common Problems

Lists common monitor issues and their potential solutions.

Product-Specific Problems

Addresses problems specific to certain monitor models and their solutions.

Appendix

Safety Instructions

Provides crucial safety warnings regarding monitor usage and adjustments.

FCC Notices and Other Regulatory Information

Directs users to regulatory compliance information and FCC notices.

Contact Dell

Provides contact information for Dell support and services.

Pin Assignments

Details the pin assignments for D-Sub, DP, and HDMI connectors.
