1. Base cover
2. USB Type-C port bracket
3. System board
4. Heat sink
5. M.2 2230 solid-state drive with bracket
6. Wireless card
7. Wireless-card bracket
8. Battery
9. Right speaker
10. Touchpad
11. Touchpad bracket
12. Left speaker
13. Display assembly
14. Palm-rest and keyboard assembly
15. I/O board cable
16. Power button with optional fingerprint reader
17. I/O board
18. Coin-cell battery
19. Right fan
20. Left fan
NOTE: Dell provides a list of components and their part numbers for the original system configuration purchased. These
parts are available according to warranty coverages purchased by the customer. Contact your Dell sales representative for
purchase options.
Base cover
Removing the base cover
Prerequisites
Follow the procedure in Before working inside your computer
NOTE:
Ensure that your computer is in Service Mode. For more information see, step 6 in Before working inside your
computer.
About this task
The following image(s) indicate the location of the base cover and provides a visual representation of the removal procedure.
Removing and installing components
11
