Replacing the speakers
WARNING: Before working inside your computer, read the safety
information that shipped with your computer and follow the steps in Before
working inside your computer. After working inside your computer, follow
the instructions in After working inside your computer. For more safety best
practices, see the Regulatory Compliance home page at
www.dell.com/
regulatory_compliance.
Procedure
NOTE: The rubber grommets may get pushed out while replacing the
speaker. Ensure that the rubber grommets are in their position after placing
the speaker on the palm-rest assembly.
1 Using the alignment posts, align and place the speakers on the palm-rest
assembly.
2 Replace the rubber grommets if they are pushed up while replacing the speaker.
3 Route the speaker cable through the routing guides on the palm-rest assembly.
4 Adhere the pieces of tape that secure the speaker cable to the palm-rest
assembly.
5 Connect the speaker cable to the system board.
Post-requisites
1 Replace the battery.
2 Replace the base cover.
41
